WM1325 CNC

شناسه محصول : 51133145

Due to currency fluctuations, price inquiries can only be made by contacting the sales department at 011433113883-8

مشخصات کلی

مدل: WM1325
توان اسپیندل: 6KW- Air Cooling
سرعت دوران اسپیندل: 18000RPM
ابعاد محیط کار: 180* 1300* 2500 mm
نیروی محرکه: Servo MOTOR
کنترلر سیستم: PC

ارسال در سریع ترین زمان

تضمین اصالت کالا

پشتیبانی و پاسخگویی

بهترین قیمت

به دلیل نوسانات ارزی استعلام قیمت فقط از طریق تماس با بخش فروش

ارسال سریع
ارسال سریع به سراسر کشور
ضمانت اصالت کالا
ضمانت اصالت کالا
اقساطی
خرید اقساطی
پشتیبانی تخصصی
پشتیبانی تخصصی

Description

Wm1325 is from WM CNC machines family that has the ability to cut and engrave two-dimensional and three-dimensional onto smooth and curved surfaces and is distributed and supplied by the Mollen Company to the country’s wood industry. The main feature of this group of CNC machines is its customization capabilities. So that you can order this device in any size of the table and in any number of spindle and rotary that it is exactly for your needs. Ordering the desired dimensions of the device is a great advantage that allows buyers to choose the machine exactly accordance with the environment and area of the workplace. Another feature of customization is the increase of the spindle motor of the machine. The main engine, mounted on the machine, is an air-cooled 6 kilowatts of Italy with a capacity of up to 9 kilowatts, as well as a spindle speed of 18000rpm, that is, the ability to rotate 18,000 times per minute.

Another advantageous feature of this device is the use of a servomotor that speeds up and accurately operates simultaneously. The type of vacuum table with circulating 7.5kW of water that holds the work piece firmly on the table is another advantage of the device. For a closer look at the device, we have a characteristic table of a list of device specifications, so that the values assigned to each feature are facing them. For a better choice of the device, paying attention to this table is essential for the buyer.

0/5 (0 Reviews)

Additional information

مدل

WM1325

توان اسپیندل

6KW- Air Cooling

سرعت دوران اسپیندل

18000RPM

ابعاد محیط کار

180* 1300* 2500 mm

نیروی محرکه

Servo MOTOR

کنترلر سیستم

PC

نوع میز

Vacuum. Wet 5.5KW

سرعت پیشروی

60 M/MIN

نمایی طولی
نحوه انتقال نیروی محورهایX.Y

Shoulder bevel gear

نحوه انتقال نیروی محورZ

Taiwan Ball Screw

توان

14KW

وزن خالص

1300 KG
